Spray Booth Air Flow Meter

All booths can be classified as either open type non pressurized or pressurized.

Spray booth air flow meter.

A 14 wide x 9 tall x 26 long spray paint booth will exhaust at least 13 104 cubic feet of air per minute. Booth spray room. The real issue with air flow in a spray paint booth is having adequate air. Even though these ventilation systems reduce vapors in the mist users still must wear appropriate respiratory equipment while painting as required by osha.

Once you have measured the air flow you will want to see what the original design specification for your paint booth airflow was. The air flow rate and ventilation system on the paint booth ensures that the airflow rate will keep the concentration of vapors in the mists below twenty five percent in the exhaust stream. The front flow booth draws air in through filtered front doors and exhausts the air out through the filter banks located at the rear of the booth this traditional style booth has been a favorite among painters for years in providing a clean environment to.
